Extends a Gigabit Ethernet signal up to 550 meters over Multimode Fiber Optic Cable
Auto detects Full/Half Duplex Transfer Mode
Supports Multimode 50/125 cable up to 550M or 62.5/125 cable up to 400M
Product description
Tripp Lite LC Multimode Fiber Media Converter Gigabit RJ45 10/100/1000 550M 850nm - 1 x Network (RJ-45) - 10/100/1000Base-T, 1000Base-SX - Desktop 1 x Network (RJ-45) - 10/100/1000Base-T, 1000Base-SX - Desktop
Specifications
Brand Name
Tripp Lite
Certifications & Standards
FCC
CE
Country of origin
China
Depth
2.8"
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Fiber Mode Supported
Multi-mode
Fiber Optic Wavelength
850 nm
Form factor
Desktop
Height
1"
Input voltage
5 V DC
Limited Warranty
2 Year
Manufacturer Part Number
N785-001-LC-MM
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's N785-001-LC-MM 10/100/1000 to Multimode Media Converter ( RJ45 to LC ) is an economical way to extend the distance of network nodes up to 550M by converting Cat5e UTP cables to Multimode Fiber Optic. The Media Converter features automatic MDI/MDI-X configuration and the UTP port senses the network speed automatically. Auto-detects half or full duplex operation on the fiber port. Power supplied by small form factor AC adapter.
Maximum Distance Supported
1804.46 ft
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
1000Base-SX
Network Technology
10/100/1000Base-T
Number of Network (RJ-45) Ports
1
Product color
Black
Product Name
10/100/1000 LC Multimode Media Converter 550M 850nm
