Tripp Lite 8-Port Rack Console KVM Switch built in IP w/ 19" LCD 1U

Tripp Lite 8-Port Rack Console KVM Switch built in IP w/ 19" LCD 1U - 8 Computer(s) - 19" LCD - SXGA - 1280 x 1024 - 2 x USB - Keyboard - TouchPad - 1U High - TAA Compliant
$4,563.32EA
Sorry Product is Currently not Available.
Availability Currently out of stock
Delivery To Not Logged in.
Region USA - Change
Great Deals Everyday
Manufacturer:
Tripp Lite by Eaton
Item:
B020-U08-19-IP
UPC Code:
012302520643
Condition
New
  • Control computers/servers locally or via LAN, WAN or Internet
  • Occupies just 1U of space in a rack-mountable drawer
  • 19" LCD screen supports video resolutions up to 1280 x 1024
  • Allows up to 64 user accounts, with multi-level security
  • Compatible with all operating systems

You may be also interested

Product description

Tripp Lite 8-Port Rack Console KVM Switch built in IP w/ 19" LCD 1U - 8 Computer(s) - 19" LCD - SXGA - 1280 x 1024 - 2 x USB - Keyboard - TouchPad - 1U High - TAA Compliant
8 Computer(s) - 19" LCD - SXGA - 1280 x 1024 - 2 x USB - Keyboard - TouchPad - 1U High - TAA Compliant

Specifications

Brand Name
Tripp Lite
Certifications & Standards

UL 60950-1 (USA) CAN/CSA (Canada) FCC Part 15 Class A CE EN 60950-1
Country of origin
Taiwan
Depth
27"
Display Screen Type
LCD
Environmental Certification
RoHS
Environmental Certification
WEEE
Height
1.7"
Input voltage
120 V AC
Input voltage
230 V AC
Keyboard
Yes
KVM Technology
Digital
Limited Warranty
1 Year
Manufacturer Part Number
B020-U08-19-IP
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's B020-U08-19-IP KVM Switch gives you a rack-mountable keyboard LCD and touchpad in a single console that occupies only 1U of rack space. From across the room down the street or halfway around the globe the B020-U08-19-IP can be accessed from any computer on the LAN WAN or Internet. Easy to install and use it's the optimal solution for controlling up to 8 computers/servers. Increase the number of connected computers up to 256 by daisy-chaining up to 31 B022-U08 KVM switches.

The B020-U08-19-IP has a built-in 19" LCD screen that supports video resolutions up to 1280 x 1024 @ 75Hz with remote monitor resolutions up to 1600 x 1200 @ 60Hz. You can switch easily between the 8 ports using on-console push buttons an on-screen display (OSD) or keyboard hot key commands. Up to 64 users can be authorized with any combination of admins and users. Multi-level security enhances protection of data and equipment.

This switch controls PS/2 or USB computers/servers using a P778-Series Combo KVM Cable Kit (two cable kits are included). A USB port on the front of the keyboard lets you connect an external mouse plus an external USB 1.1 port means you can add a peripheral that can be shared across all connected servers. When not in use the B020-U08-19-IP stores neatly in a rack drawer and pulls out when needed. This KVM console is compatible with all major operating systems. Heavy-duty steel housing stands up to frequent use.
Number of Computers Supported
8
Number of USB Ports
2
Package Contents
  • 8-Port NetDirector 1U Rackmount Console IP KVM Switch w/19" LCD
  • 2 x 6 ft. USB/PS2 Combo KVM Cable Kits
  • USB/PS2 Combo Console Cable Kit
  • Grounding Wire
  • RJ11 to DB9 firmware upgrade cable
  • Rackmount Hardware
  • C13 to 5-15P Power Cord
  • CD with Owners Manual Quick Start Guide and Device Files
  • Quick Start Guide
Platform Supported
Mac
Platform Supported
PC
Pointing Device Type
TouchPad
Product color
Black
Product Line
NetDirector
Product Material
Steel
Product Name
8-Port NetDirector 1U Rackmount Console IP KVM Switch w/19" LCD
Rack Height
1U
Screen Mode
SXGA
Screen Resolution
1280 x 1024
Screen Size
19"
UPC Alternates
012302520643 037332152886 763109107253 818242835546
Weight (Approximate)
31 lb
Width
18.9"
Manufacturer
Tripp Lite by Eaton
Product Type
LCD Rack Console
