Tripp Lite PDU Switched ATS 200-240V 16/20A 8 C13 2 C19 C20 Horizontal 1URM

Tripp Lite PDU Switched ATS 200-240V 16/20A 8 C13 2 C19 C20 Horizontal 1URM - 10 - 1U Rack-mountable, Zero U Vertical Rackmount TAA"
$1,681.76EA
Sorry Product is Currently not Available.
Availability Currently out of stock
Delivery To Not Logged in.
Region USA - Change
Great Deals Everyday
Manufacturer:
Tripp Lite by Eaton
Item:
PDUMH20HVATNET
UPC Code:
037332151506
Condition
New
  • Single phase 16/20A 200-240V Auto Transfer Switch / ATS PDU
  • Enables redundant A/B power option for non-redundant network devices
  • Built-in LX Platform Network Interface
  • 1U horizontal rackmount; 10 outlets (8 C13 switched / 2 C19 unswitched)
  • Individually switched outlets, network interface and 2 digit visual current meter
  • TAA Compliant

You may be also interested

Product description

Tripp Lite PDU Switched ATS 200-240V 16/20A 8 C13 2 C19 C20 Horizontal 1URM - 10 - 1U Rack-mountable, Zero U Vertical Rackmount TAA"
10 - 1U Rack-mountable, Zero U Vertical Rackmount TAA"

Specifications

Additional Information

Input Receptacles: 2 x IEC C20

Output Receptacles:

  • 2 x IEC C19
  • 8 x IEC C13
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
14.8"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.7"
Input voltage
230 V AC
Limited Warranty
2 Year
Manufacturer Part Number
PDUMH20HVATNET
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite Switched ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether the ATS will switch over to the secondary power source until the primary input is restored and stable. Switched PDU features include individually controllable output receptacles and built-in network interface. Super-fast switchover between primary and secondary power sources occurs within milliseconds. ATS functionality is supported by any two compatible AC power sources regardless of phase angle to support a variety of advanced redundant power networking applications. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment the primary input cable must be supported by a full time sine wave UPS with zero transfer time. Tripp Lite SmartOnline series is highly recommended for use as the primary UPS in a two-UPS application. ATS configurations utilizing separate mains circuits backup generators and even separate utility power grid feeds are fully supported. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability. Built-in LX Platform network management interface card. The Java-free LX Platform HTML5-based network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.
Mount Type
Rack-mountable
Mounting Orientation
Vertical
Output voltage
208 V AC
Output voltage
240 V AC
Output voltage
220 V AC
Output voltage
200 V AC
Package Contents
  • PDUMH20HVATNET PDU Switched ATS 200V - 240V 16A 10 Outlet
  • User Manual with Warranty Information
PDU Type
Switched
Product Name
PDUMH20HVATNET PDU Switched ATS 200V - 240V 16A 10 Outlet
Rack Height
1U
Receptacle Detail
8 x IEC 60320 C13
Receptacle Detail
2 x IEC 60320 C19
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
UPC Alternates
037332151506 074664303012 818242821945
Weight (Approximate)
10.30 lb
Width
17.3"
Manufacturer
Tripp Lite by Eaton
Product Type
PDU
