Tripp Lite UPS 550VA 300W Desktop Battery Back Up AVR Compact 120V USB RJ11

Tripp Lite UPS 550VA 300W Desktop Battery Back Up AVR Compact 120V USB RJ11 - Mini Desktop - 9 Hour Recharge - 5.50 Minute Stand-by - 110 V AC Input - 120 V AC Output - 4 x NEMA 5-15R, 4 x NEMA 5-15R
$150.88EA
Availability In Stock
Delivery To Not Logged in.
Region USA - Change
Great Deals Everyday
Manufacturer:
Tripp Lite
Item:
AVR550U
UPC Code:
003733212344
Condition
New

You may be also interested

Product description

AVR Series Line-Interactive UPS System offers 550VA ultra-compact line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space-saving right-angle input plug, four battery/surge-protected outlets and four additional surge-only outlets (8 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.



Specifications

Additional Information
  • Low voltage transfer to battery power: Switches to battery power as line voltage drops to 83V or lower / Resets to AC mode as line voltage increases to 87V or higher
  • High voltage transfer to battery power: Switches to battery power as line voltage increases to 147V or higher / Resets to line power as line voltage drops to 143V or less
  • Cold Start: Yes inverter can be "cold started" to enable temporary AC output during a power failure
  • Switches: Combination power off / on / self-test push button switch
  • Typical Application: Basic PCs for home / home-office use network workstations audio/video equipment home entertainment systems and other sensitive electronic devices.
  • WatchDog compatibility: Yes compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications
  • Supports entry-level PC systems up to 17 minutes during blackout conditions
  • Form factors supported: Ultra-compact desk/floor mount mounting flanges enable wall-mount installation
  • 8 output receptacles 2 of which are widely spaced to accommodate large transformer plugs without blocking outlets
  • 4 outlets feature full battery support and surge suppression protecting computers monitors and other vital system components from loss of power
  • 4 additional outlets with surge suppression only are ideal for printers and other peripherals not requiring battery support
  • HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows Mac OS X and Linux
Alarm
Self-test Operation
Alarm
Battery Backup
Backup/Run Time (Full Load)
5.50 Minute
Backup/Run Time (Half Load)
12 Minute
Battery life
6 Year
Certifications & Standards
  • Tested to UL1778 (USA)
  • cUL1778 (Canada)
  • NOM (Mexico)
  • FCC Class B (Emissions)
  • FCC Part 68
  • Industry Canada (Telecommunications)
Color
Black
Cord Length
6 ft
Country of origin
China
Dataline Protection
RJ-11
Depth
6"
Form factor
Mini Desktop
Height
3.5"
Hot Swappable
Yes
Input current
12 A
Input voltage
110 V AC
Limited Warranty
3 Year
Load Capacity
550 VA/300 W
Manufacturer Part Number
AVR550U
Manufacturer Website Address
http://www.tripplite.com
Maximum Operating Temperature
122°F (50°C)
Output voltage
120 V AC
Plug/Connector Type
NEMA 5-15P
Product Name
AVR 550VA Mini-Desktop UPS
Product Series
AVR
Receptacles
4 x NEMA 5-15R
Recycled
No
Software Included
PowerAlert UPS monitoring software
Status Indicators

2 LEDs indicate:

  • Line power
  • Battery power
Surge energy rating
420 J
Transfer Time
4 ms
Typical Battery Recharge Time
9 Hour
Weight (Approximate)
10.96 lb
Width
11.3"
Manufacturer
Tripp Lite
Product Type
Line-interactive UPS
